| PART NUMBER | HOSE I.D. | LENGTH | DESCRIPTION |
|---|---|---|---|
| BK-150-24 | 1-1/2" | 24" | NW 40 flange |
| BC-150-24 | 1-1/2" | 24" | 2-3/4" MET-SEAL® |
| BQ-150-24 | 1-1/2" | 24" | Quick connect |
| BT-150-24 | 1-1/2" | 24" | 1-1/2" OD tube |
| BK-150-36 | 1-1/2" | 36" | NW 40 flange |
| BC-150-36 | 1-1/2" | 36" | 2-3/4" MET-SEAL® |
| BQ-150-36 | 1-1/2" | 36" | Quick connect |
| BT-150-36 | 1-1/2" | 36" | 1-1/2" OD tube |
| KSH-5540 | 1-1/2" | 40" | NW 40 flange |
| BK-150-40.28 | 1-1/2" | 40.28" | NW 40 flange |
| BK-150-48 | 1-1/2" | 48" | NW 40 flange |
| BC-150-48 | 1-1/2" | 48" | 2-3/4" MET-SEAL |
| BQ-150-48 | 1-1/2" | 48" | Quick connect |
| BT-150-48 | 1-1/2" | 48" | 1-1/2" OD tube |
| BK-150-60 | 1-1/2" | 60" | NW 40 flange |
| BC-150-60 | 1-1/2" | 60" | 2-3/4" MET-SEAL® |
| BQ-150-60 | 1-1/2" | 60" | Quick connect |
| BT-150-60 | 1-1/2" | 60" | 1-1/2" OD tube |
| BK-200-3.94 | 2" | 3.94" | NW 50 flange |
| BK-200-6 | 2" | 6" | NW 50 flange |
| BC-200-6 | 2" | 6" | 3-3/8" MET-SEAL® |
| BQ-200-6 | 2" | 6" | Quick connect |
| BT-200-6 | 2" | 6" | 2" OD tube |
| KSH-5350 | 2" | 9.84" | NW 50 flange |
| BK-200-10.53 | 2" | 10.53" | NW 50 flange |
| BK-200-12 | 2" | 12" | NW 50 flange |
| BC-200-12 | 2" | 12" | 3-3/8" MET-SEAL |
| BQ-200-12 | 2" | 12" | Quick connect |
| BT-200-12 | 2" | 12" | 2" OD tube |
| KSH-5450 | 2" | 19.69" | NW 50 flange |
| BK-200-20.53 | 2" | 20.53" | NW 50 flange |
| BK-200-24 | 2" | 24" | NW 50 flange |
| BC-200-24 | 2" | 24" | 3-3/8" MET-SEAL |
| BQ-200-24 | 2" | 24" | Quick connect |
| BT-200-24 | 2" | 24" | 2" OD tube |
| BK-200-36 | 2" | 36" | NW 50 flange |
| BC-200-36 | 2" | 36" | 3-3/8" MET-SEAL® |
| BQ-200-36 | 2" | 36" | Quick connect |
| BT-200-36 | 2" | 36" | 2" OD tube |
| KSH-5550 | 2" | 39.4" | NW 50 flange |
| BK-200-40.53 | 2" | 40.53" | NW 50 flange |
| BK-200-48 | 2" | 48" | NW 50 flange |
| BC-200-48 | 2" | 48" | 3-3/8" MET-SEAL® |
| BQ-200-48 | 2" | 48" | Quick connect |
| BT-200-48 | 2" | 48" | 2" OD tube |
| BK-200-60 | 2" | 60" | NW 50 flange |
| BC-200-60 | 2" | 60" | 3-3/8" MET-SEAL® |
| BQ-200-60 | 2" | 60" | Quick connect |
| BT-200-60 | 2" | 60" | 2" OD tube |
Add option code to prefix of part number.
| DESCRIPTION | OPTION CODE |
|---|---|
| Flexible Hose Connector with Metal Braid Sheathing | S |
