Viton® (Fluorocarbon) O-Rings .139 cross section series
| PART NUMBER |
I.D. |
O.D. |
| VOR253 |
5.359 |
5.637 |
| VOR254 |
5.484 |
5.762 |
| VOR255 |
5.609 |
5.887 |
| VOR256 |
5.734 |
6.012 |
| VOR257 |
5.859 |
6.137 |
| VOR258 |
5.984 |
6.262 |
| VOR259 |
6.234 |
6.512 |
| VOR260 |
6.484 |
6.762 |
| VOR261 |
6.734 |
7.012 |
| VOR262 |
6.984 |
7.262 |
| VOR263 |
7.234 |
7.512 |
| VOR264 |
7.484 |
7.762 |
| VOR265 |
7.734 |
8.012 |
| VOR266 |
7.984 |
8.262 |
| VOR267 |
8.234 |
8.512 |
| VOR268 |
8.484 |
8.762 |
| VOR269 |
8.734 |
9.012 |
| VOR270 |
8.984 |
9.262 |
| VOR271 |
9.234 |
9.512 |
| VOR272 |
9.484 |
9.762 |
| VOR273 |
9.734 |
10.012 |
| VOR274 |
9.984 |
10.262 |
| VOR275 |
10.484 |
10.762 |
| VOR276 |
10.984 |
11.262 |
| VOR277 |
11.484 |
11.762 |
| VOR278 |
11.984 |
12.262 |
| VOR279 |
12.984 |
13.262 |
| VOR280 |
13.984 |
14.262 |
| VOR281 |
14.984 |
15.262 |
| VOR282 |
15.955 |
16.223 |
| VOR283 |
16.955 |
17.233 |
| VOR284 |
17.955 |
18.233 |
