HDME Series Oil Mist Eliminators should be used on every rotary vane pump exhaust port. Oil mist/vapor will be exhausted from the pump's exhaust into the atmosphere whenever the pump operates between the atmosphere and one millibar. The higher the inlet pressure, the more oil mist/vapor will be expelled into the work area. This mist is unhealthy to breathe and will leave an oily residue on lab equipment.
Key High's Oil Mist Eliminators, a trusted and proven solution, effectively capture oil mist, providing you with the confidence that your work environment is clean and healthy. The oil is separated from the air using a multistage fiberglass element, causing the oil to coalesce. Oil Mist Eliminators should be mounted vertically, allowing the oil to drain back into the pump. This creates a cleaner, healthier environment.
HDME Series Construction
Key High's heavy-duty oil mist eliminaters feature right-angle mounting, constructed from carbon steel with a baked enamel finish. HDME Series Oil Mist Eliminators have female NPT inlet and outlet ports and come with a ¼" drain plug. We can provide alternate trapping media for aggressive gases and organic compounds upon request.
HDME Series Oil Mist Eliminators
PART NUMBER
FNPT
A
B
C
D
E
CFM
HDME-1
1"
6-3/4"
1/2"
7-5/16"
4-5/8"
5-1/4"
40
HDME-2
1-1/2"
6-3/4"
1/2"
7-5/16"
4-5/8"
5-1/4"
50
PART NUMBER
USE WITH
RF-HDME-1
HDME-1/HDME-2
Product information is subject to change without notice. Product images may include options or accessories not included with the base model.
