CPB SERIES
The CPB / CPS SERIES adapters for gauge tubes are intended to allow the user to use standard gauge tubes in existing equipment with non standard ports. These adapters are available in brass and stainless steel bodies and are complete with Viton® O-ring.
| PART NUMBER | DESCRIPTION |
|---|---|
| CPB-625-750-BR | Brass 5/8" OD male tube to 3/4” compression |
| CPB-709-750-BR | Brass .709 OD male tube to 3/4” compression |
| CPB-750-1000-BR | Brass 3/4” OD male tube to 1" compression |
| CPS-625-750-SS | Stainless steel 5/8" OD male tube to 3/4” compression |
| CPS-709-750-SS | Stainless steel .709 OD male tube to 3/4” compression |
| CPS-750-1000-SS | Stainless steel 3/4” OD male tube to 1" compression fitting |
ELC SERIES
90° UNION ELBOW COMPRESSION ADAPTER
Key High's ELC Series compression adapters are a reliable solution for many applications. No tools are required to assemble or disassemble. ELC Series allows easy finger-tight assembly and offers dependable sealing performance.
These elbows are manufactured from stainless steel type 304 which is electropolished per ASTM B912. All compression fittings are cleaned, packaged, and ready for immediate use.
Final assemblies are leak tested at 2 x 10-10 std cc/sec He. Optional sealing materials are available upon request.
| PART NUMBER | DESCRIPTION | A | B | C | D | E |
|---|---|---|---|---|---|---|
| ELC-25 | For 1/4” OD tube | .265 | .187 | 7/8" | 1/2” | 5/8" |
| ELC-37 | For 3/8" OD tube | .385 | .312 | 1-1/2" | 1" | 1" |
| ELC-50 | For 1/2” OD tube | .515 | .437 | 1-1/2" | 1" | 1-1/4" |
