Combination Valves, Stainless Steel, Electropneumatic, Viton® Bonnet and Poppet
| PART NUMBER | TUBE OD | PORT STYLE | A | B | C |
|---|---|---|---|---|---|
| CSAL-75-P | 3/4” | Tube End | 5.01 | 3.70 | 2.00 |
| CSAL-75-P-K | 3/4” | NW 16 | 5.01 | 4.70 | 2.00 |
| CSAL-75-P-MS | 3/4" | Mini MET-SEAL | 5.01 | 4.01 | 2.00 |
| CSAL-100-P | 1" | Tube End | 5.02 | 3.90 | 2.00 |
| CSAL-100-P-K | 1" | NW 25 | 5.02 | 4.23 | 2.00 |
| CSAL-100-P-MS | 1" | 2-1/8" MET-SEAL | 5.02 | 4.20 | 2.00 |
| CSAL-150-P | 1-1/2" | Tube End | 5.40 | 4.82 | 2.75 |
| CSAL-150-P-K | 1-1/2" | NW 40 | 5.40 | 5.12 | 2.75 |
| CSAL-150-P-MS | 1-1/2" | 2-3/4" MET-SEAL | 5.40 | 5.24 | 2.75 |
| CSAL-200-P | 2" | Tube End | 7.40 | 6.70 | 3.50 |
| CSAL-200-P-K | 2" | NW 50 | 7.40 | 7.15 | 3.50 |
| CSAL-200-P-MS | 2" | 3-3/8" MET-SEAL | 7.40 | 7.00 | 3.50 |
Combination Valves, Stainless Steel, Electropneumatic, OFHC® Bonnet and Viton® Poppet
| PART NUMBER | TUBE OD | PORT STYLE | A | B | C |
|---|---|---|---|---|---|
| CSAL-75-P-C | 3/4” | Tube End | 5.01 | 3.70 | 2.00 |
| CSAL-75-P-MS-C | 3/4” | Mini MET-SEAL | 5.01 | 4.01 | 2.00 |
| CSAL-100-P-C | 1" | Tube End | 5.02 | 3.90 | 2.00 |
| CSAL-100-P-MS-C | 1" | 2-1/8" MET-SEAL | 5.02 | 4.20 | 2.00 |
| CSAL-150-P-C | 1-1/2" | Tube End | 5.40 | 4.82 | 2.75 |
| CSAL-150-P-MS-C | 1-1/2" | 2-3/4" MET-SEAL | 5.40 | 5.12 | 2.75 |
| CSAL-200-P-C | 2" | Tube End | 7.40 | 6.70 | 3.50 |
| CSAL-200-P-MS-C | 2" | 3-3/8" MET-SEAL | 7.40 | 7.00 | 3.50 |
Gasket Kits for CSAL Valves
Viton® Gasket Kits
| PART NUMBER | FITS VALVE SERIES |
|---|---|
| OR-PSA-100-N | 75,100 |
| OR-PSA-150-N | 150 |
| OR-PSA-200-N | 200 |
Gasket Kits OFHC® Bonnet, Viton® Poppet
| PART NUMBER | FITS VALVE SERIES |
|---|---|
| OR-PSA-100-N-C | 75,100 |
| OR-PSA-150-N-C | 150 |
| OR-PSA-200-N-C | 200 |
Options: add code to suffix of part number
| DESCRIPTION | OPTION CODE |
|---|---|
| 24 Volt DC solenoid | -24VDC |
| 24 Volt AC solenoid | -24VAC |
| 220 Volt AC solenoid | -220VAC |
| Mechanical limit switches | -LS |
| No solenoid | -NS |
Pneumatic Bellows Assemblies
| PART NUMBER | FITS VALVE SERIES |
|---|---|
| PRS-B-100-N | 75,100 |
| PRS-B-150-N | 150 |
| PRS-B-200-N | 200 |
Product information is subject to change without notice. Product images may include options or accessories not included with the base model.
