SRV-25

Safety Relief Valves

Key High’s Safety Relief Valves (SRV Series) are spring-loaded, direct-acting safety devices. The SRV Series are designed as protection devices that vent positive pressure to the atmosphere. These valves feature highly accurate cracking and reset pressures. Key High’s SRV valves will virtually eliminate dangerous overpressure situations in many vacuum systems.

Construction

Construction is made from vacuum-grade materials: a stainless-steel body, a stainless-steel spring, and a Viton® seat. Every valve is 100% tested prior to shipment. SRV valves will protect expensive gauges, viewports, etc., in the event of most overpressure situations.

Types

Key High offers the SRV Series with two different cracking pressures. 0.2 psig or 2.0 psig.  SRV Valves are mounted on NW 25 or NW 40 flanges.





SRV Series Ordering Information

SRV Series Ordering Information

SRV Series Ordering Information


PART NUMBER FLANGE MOUNT CRACKING PRESSURE
SRV-25 ★ NW25 0.2 PSIG
SRV-40 ★ NW40 0.2 PSIG
SRV-25-125 NW25 2.0 PSIG
SRV-40-125 NW40 2.0 PSIG

Note: ★ - The 0.2 psig "cracking pressure" valves must be installed with the poppet in the vertical position. Other flange mountings are available upon request.


Product information is subject to change without notice. Product images may include options or accessories not included with the base model.
